Changing the Heel Dies (cont.)
6. Grease the back of the new Die.
7. Insert the new Die into the Die
Holder (DH) with the teeth of the
Die facing out.
8. Place the Die Holder (DH) back
in the Die Pivot Block (DB).
9. Insert the Heel Die Pin (P).
10. Use the 3/4" wrench to replace the
Heel Die Bolts (B) and Lock
Washers.
Maintenance & Repair 45
Maintenance
&
Repair
Part Name Part #
Die Holder Bolt (B) 999-806246
Die Holder Bolt Washers 999-810703
Die (D) 061-20194
Die Holder (DH) 061-30001
Part Numbers
