Hanger assembly – Hawk Industries Hawkjaw Jr. Manual 65K-ALS Serial Numbers 4 to 9 User Manual
Page 133
1
2
3*
4
5
6*
7*
8
9
10
11
12
13
14
15
16*
17
18
19**
20
21*
22
23
24
25
26
27
061-20230
999-806622
999-806594 500
061-H20
999-806540
999-806532
999-806503
002-13143
002-13179-2
999-806510
999-805842
061-91074A029
061-20180
061-J25
999-806511
999-806503
999-98025A036
061-PRP-568-325
061-807493-125
061-30048
999-806221
999-806289
999-806503
061-3022T55
999-805842
061-91074A029
061-J2
Swivel
Hex Bolt
Flex Lock Nut
Raise/Lower Cylinder
Hex Bolt
Flex Lock Nut
Flex Lock Nut
Suspension Ring
Lateral Tilt Screw
Hex Bolt
Hex Bolt
Lock Washer Set
Torque Gage Mount
Torque Gage
Hex Bolt
Flex Lock Nut
Washer
"O" Ring
Cotter Pin SS
Hanger Assy.
Flex Lock Nut
Hex Bolt
Flex Lock Nut
Turnbuckle SS
Hex Bolt
Lock Washer Set
Spin Hyd. Manifold
1
1
7
1
4
7
3
1
1
1
7
3
1
1
2
3
2
1
32
1
3
2
3
1
7
3
1
Part Name
Quantity
Per Unit
Item
Part #
Hanger Assembly
Drawings
133
Drawings
CAUTION
* Check periodically to ensure all Flex Lock Nuts
are securely tightened.
WARNING
**To ensure operator safety, the Cotter pin must be
installed at all times.
30hanger
1/97
