Table of Contents (cont.)
Continued on next page.
4 Table of Contents
Filter Maintenance 35
Hydraulic Filter 35
Air Filter 36
Changing the Hook Dies 37
Hook Dies 37
Changing the Heel Dies 38
Top Wrench Heel Die 38
Middle Wrench Heel Die 40
Bottom Wrench Heel Die 42
Spinner Maintenance 44
Chain 44
Drive Roller Sprocket Bearings 45
Spinner Grip Cylinders 46
Chain Drive Shaft Bearing 46
Spinner Mount Sliding Tube 47
Reducer Gear Box 47
Changing the Spinner Chain 48
Chain 48
Changing the Drive Rollers 50
Drive Rollers 50
Changing the Drive Roller Sprocket Bearings 52
Drive Roller Sprocket Bearings 52
Changing All Other Spinner Parts 54
Changing the Torque Cylinder 54
Torque Cylinder 54
Torque Cylinder Seals 58
Changing the Grip Cylinders 59
Top Grip Cylinder 59
Grip Cylinder Seals 60
Middle Grip Cylinder 61
Grip Cylinder Seals 64
Bottom Grip Cylinder 65
Grip Cylinder Seals 66
Changing All Other HawkJaw Parts 66
Trouble Shooting 67
Leaks at Start-up 67
Movement at Start-up 67
Raise Button /Lower Button 69
