7.7. DIP switch
Over the DIP switches the serial interfaces mode as well as the monitor address can be adjusted.
With the distribution (default) are all DIP switches on OFF. This meant, the monitor is adjusted in address 0 in RS 232
mode.
4 DIP switches are for coding addresses, 16 addresses can be realized binary (0 – 15).
Therefore it is possible to connect 16 monitors over the RS485 interface.
Serial Mode:
DIP Switch 1
Mode
ON
RS 485
OFF
RS 232 (default)
Monitor Addresses:
Address
DIP Switch 2
DIP Switch 3
DIP Switch 4
DIP Switch 5
0
OFF
OFF
OFF
OFF
1
ON
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
3
ON
ON
OFF
OFF
4
OFF
OFF
ON
OFF
5
ON
OFF
ON
OFF
6
OFF
ON
ON
OFF
7
ON
ON
ON
OFF
8
OFF
OFF
OFF
ON
9
ON
OFF
OFF
ON
10
OFF
ON
OFF
ON
11
ON
ON
OFF
ON
12
OFF
OFF
ON
ON
13
ON
OFF
ON
ON
14
OFF
ON
ON
ON
15
ON
ON
ON
ON
