Page 16

Installati-

on RGB

Mode

push

Adjustment to video signals those Timing

data are not stored (if the indicated resoluti-

on at the display does not correspond to the

resolution of the source).With push of the

<+>-key, 9 adjustment possibilities appear

At <+>,
- H- and V-

Frequency

–

Indicate H/V frequency of the current video

source

- H/V-total,

H/V-start

–

Indicate the used timing parameters of the

current video source

- Options

Var. RGB-Mode inactively, Mode1, Mode2,

Mode3

Inactively: only using the internal timing

tables Mode1: use the adjusted parameters

with complete, automatic alignment (usually

used)Mode2: use the adjusted parameters

with complete automatic alignment without

the automatic „position“ alignmentMode3:

use the adjusted parameters with complete-

ly automatic alignment without the automatic

„frequency“ alignment

- H-visible 100 to 2000 over adjustment keys (UP /

DOWN)

Horizontal picture resolution adjust (most

important parameter)

- V- visible 100 to 2000 over adjustment keys (UP /

DOWN)

Vertical picture resolution adjust (most im-

portant parameter)

- H- totally 100 to 2000 over adjustment keys (UP /

DOWN)

Number of entire pixels in a line adjust (most

important parameter)

- H-Start

0 to 750 over adjustment keys (UP / DOWN) Number of pixels from H-Sync-start to the

beginning of the picture adjust

- V-Start

0 to 500 over adjustment keys (UP / DOWN) Number of lines from V-Sync-start to the

beginning of the picture adjust

- Install

push

Adjusted timing parameter are activated

Test sam-

ple

push

Representation of a test picture

Infos

Firmware,

Actual

working

time and

signal in-

formation

–

Displaying of the current signal source

represented by firmware conditions, actual

working time and the Backlight and signal

information such as resolution, H and V-

frequency
