Beijer Electronics MT 223 EN User Manual

Page 17

6.4.4. Structure of the OSD menu (Digital/DVI)

Main

menue

Function

Adjusting/setting/range of adjustment

Description


Brightness Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

Brightness adjustment

Contrast

Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

Contrast adjustment

Advanced Structure of menu the same as the structure of the OSD menu (RGB)
Option 1

Structure of menu the same as the structure of the OSD menu (RGB)

Option 2

Structure of menu the same as the structure of the OSD menu (RGB)

Option 3

Structure of menu the same as the structure of the OSD menu (RGB)

Utilities

Structure of menu the same as the structure of the OSD menu (RGB)

Info

Structure of menu the same as the structure of the OSD menu (RGB)

6.4.5. Structure of the OSD menu (video)

Main me-

nue

Function

Adjusting/setting/range of adjustment

Description

Screen

Bright-

ness

Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

Brightness adjustment

Contrast Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

Contrast adjustment

H Position Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

Picture in horizontal direction shift

V-Position Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

Picture in vertical direction shift

Phase

Range of adjustment: 0 to 31 over adjust-

ment keys (UP / DOWN)

Phase of the input signal adjust

Frequen-

Range of adjustment:950 to 1050 (picture-

dependently)over adjustment keys (UP /

DOWN)

Frequency of the input signal adjust

Scaling

Format filling; (correct aspect ratio); 1:1

representation

Fix, pre-defined scaling of the pictureIf „va-

riable“ is activated, the setting can be made

manually.

Advanced Structure of menu the same as the structure of the OSD menu (RGB)
Video

Video

format

Auto, NTSC, PAL, SECAM

Selection of the video format

PIP

Structure of menu the same as the structure of the OSD menu (RGB)

Scale

Display

width

Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

setting of the display width

H- Linea-

rity

Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

Attitude of the horizontal linearity. Values

> 50 compress the picture in the picture

center. Only actively if the display width is

larger than the size of the monitor. Values <

50 stretch the picture in the picture center.

The display width is not changed.

H-Posi-

tion

Range of adjustment: 0 to 100 over adjust-

ment keys (UP / DOWN)

Attitude of the horizontal picture position.

Actively only if the picture width is larger

than display width of the screen surface.
