6.1. Power On / Off Switch + Power-LED

With the power On / Off switch (1) the monitor will be powered up and shut down, without disconnecting the power

supply . The bright LED indicates the switched on condition.

6.2. Brightness

With the keys (2) contrast+ and (3) contrast– the contrast is regulated.

(2) brightness + increments (increased) the contrast

(3) brightness – decrements (decreased) the contrast

6.3. ECDIS-Mode

With the ECDIS key (4) the brightness as well as the colors are set on a certain default value. See also chapter pro-

gramming.

The bright LED indicates the switched on ECDIS mode.

ATTENTION:

If the ECDIS key is activated (LED on) automatically all other keys (contrast, OSD..)

are not active and cannot be operated.

Likewise no commands and/or programming over the serial and/or LAN (Ethernet) interface can be sent and accom-

plished.

6.4. OSD Menu

The OSD menu (on screen display menu) serves for adjustment and alignment of the monitor parameters e.g. con-

trast, brightness, zoom , video source etc..

The menu is divided into a „

Quick OSD menu „ as the parameters brightness as well as contrast can be changed,

and a „

OSD menu„ with all parameters are available.

6.4.1. Quick-OSD-Menu

The keys have the following Function(s):

Keys

Function

Quick-OSD-Menu-Start:
Increase the values
Selection of the Input source
Automatic screen alignment accomplish

Adjusting parameter value degrade

MENÜ

No function in the Quick OSD menu

SET

Quick OSD menu start:
Adjustment of contrast, brightness
Adjustment of contrast, brightness
Adjustment of contrast, brightness
