Display Resolution of display Indicate to the physical resolution of the
attached display
Info Signal
source
On – Off Signal source info display switch on or offIn
the case of change one of the following set-
ting appears on the screen briefly the signal
source info with the current signal source
information:- Signal source (e.g. RGB simi-
larly)- Mode (number of the table entry of the
internal Time table)- Resolution of the input
video source- H and V frequency
Options 3 Inter-
ference
suppres-
sion
On – Off Default setting OFF.ON: Activation of the
function for the suppression of interferences
in the synchronisation signals. It prevents
a renewed picture alignment during the
representation of a video signal when inter-
ferences are on the synchronisation signals.
RGB-Si-
gnal 1 lock
ON Default setting: OFF.ON: The straight
represented Videotiming is stored and
processed with a higher tolerance in H and
V-frequency. I.e. the attitudes of this timings
are always used, even if by interferences
variations in H and V-frequency arise. It pre-
vented when recognizing one interference
afflicted video signal an incorrect timing re-
cognition e.g. in an incorrect picture centring
or picture resolution presents itself.
RGB-
Signal 1
unlock
OFF Default setting: OFF.(Video timing 1 again
releases)
RGB-Si-
gnal 2 lock
ON Default setting: OFF.ON: The straight
represented Videotiming is stored and
processed with a higher tolerance in H and
V-frequency. I.e. the attitudes of this timings
are always used, even if by interferences
variations in H and V-frequency arise. It pre-
vented when recognizing one interference
afflicted video signal an incorrect timing re-
cognition e.g. in an incorrect picture centring
or picture resolution presents itself..
RGB-
Signal 2
unlock
OFF Default setting: OFF.(Videotiming 2 again
releases)
Utilities Language English – German Language for the operation of the OSD
menu select
freeze
ON – OFF Store (freeze) the picture content
Factory
setting
push Reset all functions such as brightness, con-
trast… on factory settings.
Mode
Video
normally, extended The function „extended“ activates a special
interlace algorithm. This attitude improves
the representation, particularly of static
video pictures.This attitude affects only on
video signals (PAL, SECAM,NTSC) which
are in full screen mode (no PIP.
