Contents
a non-hot-plug slot 74
Hot-swap SCSI drives 77
Checking a hot-swap SCSI drive status indicator 77
Installing and removing a hot-swap drive
in a carrier
78
Removing and installing hot-swap disk drives 80
DC power supplies 83
Checking the power supply LED status indicators 83
Removing and installing a power supply module 84
Cooling system fans 87
Checking a fan status indicator 87
Removing and installing a fan module 88
Backup battery 89
Replacing the battery 89
Front panel board 91
Installing the front panel board 91
Diskette drive 93
Replacing the diskette drive 93
5.25-inch peripheral drives 96
Preliminary considerations 96
Removing and installing a 5.25-inch
peripheral drive
97
Hot-swap drive bays 100
Removing and installing a hot-swap drive bay 100
Power distribution board 103
Replacing the power distribution board 103
Fan distribution board 105
Replacing the fan distribution board 105
Foam fan baffle 107
Removing and installing the foam fan baffle 107
Hot-plug indicator board 109
Replacing the hot-plug indicator board 109
4 BIOS setup 111
BIOS setup 113
Recording BIOS settings 113
Clearing CMOS memory 113
Using BIOS setup 114
Main 116
Primary IDE Master/Slave 118
Processor Settings 120
