Avaya P130 SMON User Guide 58
SMON Dialog Boxes
Using the Define Port Filter Dialog Box
To open the Define Port Filter dialog box:
1. Click .
Or
Select Actions > Define Port Filter . The Define Port Filter dialog box
opens.
Figure A-7. Define Port Filter Dialog Box
* Note: Filtering changes are only applied after clicking Apply .
To add ports to the List of Selected Ports :
Select ports from the List of Known Ports and click Add .
Or
Double-click ports in the List of Known Ports . The selected ports
appear in the List of Selected Ports .
To select all ports, click Add All . All ports are added to the List of Selected
Ports .
