Avaya P130 SMON User Guide

30

VLAN Statistics

Selecting VLANs to Display

By default, information from all VLANs is displayed in the VLAN Statistics

window. You can limit information being displayed to specific VLANs

using VLAN and TopN filters. For more information, refer to

Appendix A,

Using the Define VLAN Filter Dialog Box

, and

Appendix A, Using the Define

TopN Filter Dialog Box

.

VLAN Statistics Variables

The following graphics provide examples of VLAN Statistics windows.

Each figure is followed by a list of variables available in each of the

windows.

Figure 6-1. VLAN Statistics Window - Packets

Table 6-1. VLAN Statistics Variables - Packets

Variable

Description

Good Broadcasts/

Multicasts Into Switch

The number of good non-unicast packets

entering the switch.

Good Unicasts Into

Switch

The number of good unicast packets entering

the switch.
