Appendix A
53 Avaya P130 SMON User Guide
Using the ExtPort/Switch Options Dialog Box
This dialog box enables you to change the display options for Switch
Statistics and Extended Port Statistics for the Avaya P130 Device.
To access the Switch Options dialog box:
1. Click .
Or
Select File > Options . The Options dialog box opens.
2. Click the ExtPort/Switch tab at the top of the dialog box. The
Extended Port/Switch Options dialog box opens.
Figure A-4. ExtPort/Switch Options Dialog Box
* Note: Changes made in the ExtPort/Switch Statistics Options dialog
box apply to Extended Port Statistics and Switch Statistics.
The ExtPort/Switch Options dialog box enables you to change the
following options:
• Samples Per Screen
• Samples To Store
• Logarithmic Display
• Level Indicators
