March 24, 2010 Page 17 of 17
© 2010 HID Global Corporation. All rights reserved.
OMNIKEY 2061 Bluetooth Reader 2061-905_ A.1
User Manual, Firmware V1.27
6.2 Toshiba Bluetooth Stack
1. Power on the OMNIKEY 2061 Bluetooth reader. The green LED is illuminated. If not verify
the batteries are charged.
2. Pair the reader with the host:
a. Open the Bluetooth dialog; click Start > Programs > TOSHIBA > Bluetooth >
Bluetooth Settings.
b. Follow the dialog, click Next.
c. Select your OMNIKEY 2061 Bluetooth reader from the list of found Bluetooth
devices and click Next.
d. The assigned COM port is displayed. The COM port number is needed for the
driver configuration.
e. Click Next to finish the pairing process.
3. Open a command shell and switch to the installation directory of the configuration
software. The default path is C:\Program Files\HID Global\OMNIKEY 2061 Bluetooth.
4. Install a driver instance by calling OK2061_install.bat. For this step, required are
administrative privileges.
5. Configure the driver:
a. Open the registry editor.
b. Change to
HKLM\System\CurrentControlSet\Enum\Root\SMARTCARDREADER
c. Select the corresponding driver instance key, for example 0000. Select the Device
Parameters key of the corresponding driver instance key.
d. Add a new DWORD Value Port and set the assigned Outgoing COM port for this
value.
6. The driver connects the OMNIKEY 2061 Bluetooth reader and the Bluetooth Security
dialog is displayed. Enter the reader PIN. The reader is connected and operable.
