2061-905_A.1 OMNIKEY 2061 Bluetooth Reader
User Manual, Firmware V1.27
Reader Installation). Manual installation is recommended only for experienced users with
administrative privileges. Ensure that your Bluetooth radio is connected and operable.
Define a common name for the device before installation. See details in section 4.2.3 Installation
Properties.
The default device PIN is 0000. For security reasons it is recommended to set a more secure PIN
as described in section 4.2.6 Set Reader PIN.
6.1 Microsoft Bluetooth Stack
1. Power on the OMNIKEY 2061 Bluetooth reader. The green LED is illuminated. If not,
verify the batteries are charged.
2. Pair the reader with the host:
a. Open the Bluetooth dialog by clicking Start > Control Panel > Bluetooth
Devices.
b. Search the OMNIKEY 2061 Bluetooth reader, click Add….
c. Check My device is set up…
d. Select your OMNIKEY 2061 Bluetooth reader from the list of found Bluetooth
devices, click Next.
e. Check Use the passkey… and enter the device PIN.
f. If successful, the Outgoing COM port is displayed in the dialog. This port number is
needed for driver configuration.
3. Open a command shell and go to the installation directory of the configuration software.
The default path is C:\Program Files\HID Global\OMNIKEY 2061 Bluetooth.
4. Install a driver instance by calling OK2061_install.bat. For this step required are
administrative privileges.
5. Configure the driver:
a. Open the registry editor.
b. Change to
HKLM\System\CurrentControlSet\Enum\Root\SMARTCARDREADER
c. Select the corresponding driver instance key, for example 0000. Select the Device
Parameters key of the corresponding driver instance key.
d. Add a new DWORD Value Port and set the assigned Outgoing COM port for this
value.
