HID DTC1000/4000 User Guide - Manual (Page 12)

© 2012 HID Global Corporation All rights reserved
DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
12
Technical Specifications
Term Function
Input Hopper Card
Capacity 100 c ards (.030” / .762.mm) DTC1000, DTC1000M, DTC4000
200 cards (.030” / .762 mm) DTC4000 (Dual Hopper)
Output Hopper Card
Capacity
100 cards (.030” / .762.mm) DTC4000
30 cards (.030” / .762.mm) DTC1000
Reject Hopper Card
Capacity 100 cards (.030” / .762.mm) – same-side Input/Output Card
Hopper (required)
Card Cleaning Card cleaning roller integrated into the Ribbon Cartridge.
A new cleaning roller is included with each Ribbon Cartridge.
Printer Memory 32MB RAM
Software Driver Windows® XP / Vis ta™ (32 bit & 64 bit) / Server 2003 & 2008 /
Windows® 7 (32 bit & 64 bit) / Linux®
Interface USB 2.0 and Ethernet with internal print server
Operating
Temperature 65 degrees to 80 degrees F / 18 degrees to 27 degrees C
Humidity 20-80% non-condensing
Dimensions Here are the dimensions for the DTC1000:

Single-Sided Printer: 8.8˝H x 13.7˝W x 7.9˝D / 224mmH x
348mmW x 201mmD (DTC1000M)

Dual-Sided Printer: 9.8˝H x 18.7˝W x 9.2˝D / 249mmH x
475mmW x 234mmD
Here are the dimensions for the DTC4000:

Single-Sided Printer: 9.8˝H x 18.1˝W x 9.2˝D / 249mmH x
460mmW x 234mmD

Dual-Sided Printer:
9.8˝H x 18.7˝W x 9.2˝D / 249mmH x
475mmW x 234mmD
Weight Single-Sided: 8 lbs. / 3.63 Kg; Dual-Sided: 10 lbs. / 4.54 Kg
Agency Listings Safety: UL 60950-1, CSA C22.2 (60950-1), and CE; EMC; FCC
Class A, CRC c1374, CE (EN 55022 Class A, EN 55024), CCC,
BSMI, KCC
