DTC1000/DTC1000M/DTC4000 Card Printer/Encoder User Guide (L001398, Revision 1.5)
11
Technical Specifications
Term Function
Print Speed

7 seconds per card (K*)

12 seconds per card (KO*)

24 seconds per card (YMCKO*)

31 seconds per card (YMCKOK*)

Print speed indicates an approximate batch print speed and
is measured from the time a card feeds into the Printer to the
time it ejects from the Printer.

Print speeds do not include encoding time or the time
needed for the PC to process the image.

Process time is dependent on the size of the file, the CPU,
amount of RAM and the amount of available resources at the
time of the print.
* Indicates the Ribbon type and the number of Ribbon panels
printed where Y=Yellow, M=Magenta, C=Cyan, K=Resin Black,
O=Overlay, F=Fluorescing Resin
Card Size and
Types Supported

CR-80 (3.375"L x 2.125"W / 85.6mmL x 54mmW)

CR- 79 (3.313”L x 2.063”W / 84.1mmL x 52.4mmW
Accepted Standard
Card Sizes

CR-80 edge-to-edge (3.36"L x 2.11"W / 85.3mmL x
53.7mmW)
 CR- 79 (3.3”L x 2.04”W / 83.8mmL x 51.8mmW)
Accepted Card
Thickness .009” - .040” / 9 mil – 40 mil / .229mm – 1.016mm
Accepted Card
Types PVC or polyester cards with polished PVC finish; monochrome
resin required for 100% polyester cards; optical memory cards
with PVC finish; rewrite
