Optimum conditions for taking a thermal reading are:
• (outdoors) stable weather conditions / cloudy sky before and during the measurement
• (outdoors) no direct solar radiation before and during the measurement
• (indoors / outdoors) dry conditions / no precipitation
• (indoors / outdoors) clean surfaces
NOTE: Your ROTHENBERGER Thermal Imager is factory calibrated with an optimum focal range of
2 m, which maximizes the thermal overlay properties and image alignment with that of the visual
properties of the camera. This was determined based on the typical indoor work environment of
the plumber.
6
Cleaning Instruction
1. Damp alcohol wipes or mild detergent and water to remove dirt and grease from the exteri-
or plastic surface of the product.
2. Recommended soft optical cloth for cleaning the lens and Germanium thermal lens.
(Note - do not use liquids of any kind on either lens.)
3. Allow appropriate drying time before operating Hand-Held device after cleaning.
7
Storage
1. It is good practice to clean the unit prior to long term storage
2. It is best to store the unit in a cool/ dry location.
8
Troubleshooting
Symptom
Possible Reason
Solution
Apparently inaccurate
temperature reading
Improper emissivity for
surface being measured
Refer to user guide / Emissivity
Table
Thermal image doesn’t
align with true image
Outside of optimal range of
thermal overlay
Refer to specification in manual
(2m)
limited thermal properties
registered on LCD
Max. / Min. Temp. Settings
are too close together
Adjust Max. / Min. Temp
settings apart to add range
Washed out Thermal
properties on LCD
Opacity setting is too low /
showing minimal thermal
properties
Adjust the opacity setting to
add more thermal properties to
the overlay image
Unit is non-responsive
(turning on)
Battery requires additional
charge
Plug base unit in for full charge
refer to user guide for either
ROSCOPE 1000 (or) ROSCOPE
i2000
Thermal reflections shown
on surface
Polished surfaces reflect
thermal radiation
Product not suitable for
measuring highly polished
surfaces which effect Emissivity
9
Accessories
Accessory Name
ROTHENBERGER Part Number
ROSCOPE 1000
No. 69601
ROSCOPE i2000
No. 1500000696
Modul 25/16 (16m Imager Reel)
No. 1500000052
Modul ROLOC PLUS (Line Finder)
No. 1500000057
