89 SPEKTRUM DX6i • RADIO PROGRAMMING GUIDE
SwASh TyPE
The DX6i offers 2 swashplate types:
One Servo: 90 degrees (standard mechanical mix)
Three Servo: CCPM 120 degrees
Select the swashplate type to match your helicopter.
TO SElECT ThE SwAShPlATE TyPE
Press the ROLLER and hold while turning on the transmitter. When SETUP LIST appears on screen
release the roller.
Alternatively the setup list can be accessed from the main screen by pressing the roller to access the ADJUST LIST,
then scrolling through the ADJUST LIST by rolling the roller to highlight SETUP LIST, then pressing the roller.
Reduce photo to 13.5%
ADJUST LIST
MODEL SELECT
Main
Rotate the roller to highlight SWASH TYPE then press the roller to access the swashplate type function.
Reduce photo to 13.5%
ADJUST LIST
5
REVERSE
SWASH TYPE
THRO CUT
Main
