Spektrum DX6i - Manual (Page 118)

118 SPEKTRUM DX6i • RADIO PROGRAMMING GUIDE
ThROTTlE CURvE
The DX6i offers two (2) separate throttle curves with five (5) adjustable points per curve. This function allows
you to adjust the throttle curve to optimize engine rpm at a particular pitch setting. Once the throttle curves are
established, each can be activated in flight using the 2-position flight mode switch. The flight mode switch offers
two (2) selectable curves: 0=Normal, 1=Stunt.
The 0, or Normal, position should be used for starting the engine and hovering. Position 1, or Stunt, should be
used for aerobatic maneuvers and forward flight.
Each of the five (5) positions of the throttle curve are independently adjustable from 0–100%. These five (5)
positions correspond to the position of the throttle stick.
The transmitter is factory preset to the throttle curve as indicated by the solid line in the figure below. Individual
points can be activated and increased/decreased to suit your specific needs.
TO ACCESS ThE ThROTTlE CURvE fUNCTION
With the transmitter already powered on and the main screen displayed, press and release the ROLLER to
enter the ADJUST LIST.
Reduce photo to 13.5%
ADJUST LIST
MODEL SELECT
Main
Rotate the ROLLER to the right until THRO CUR is highlighted on screen.
Reduce photo to 13.5%
ADJUST LIST
6
GYRO
THRO CUR
PITC CUR
Main
