125 SPEKTRUM DX6i • RADIO PROGRAMMING GUIDE
PROGRAMMAblE MIXING 1 AND 2
The DX6i offers two programmable mixes that allow stick or switch inputs to control the output of two or more
servos. This function allows mixing any one channel to any other channel, or the ability to mix a channel to itself.
The mix can remain ON at all times, or it can be switched OFF in flight, using a number of different switches. Mix
values are adjustable from -125% to 125%. Each channel is identified by a four-character name (i.e., Aileron -
AILE, Elevator - ELEV, etc.). The channel appearing first is the master channel. The second channel is the slave
channel. For example, AILE - RUDD would indicate aileron-to-rudder mixing. Each time the aileron stick is moved,
the aileron will deflect, and the rudder will automatically move in the direction and to the position based on the
value input in the programmable mix screen. Mixing is proportional, so small inputs of the master channel will
produce small outputs of the slave channel. Both mixes offer a trim feature that, when activated, affect the master
channel’s trim and also the slave channel.
ACCESSING PROGRAMMAblE MIX 1 OR MIX 2
With the transmitter already powered on and the main screen displayed, press and release the ROLLER to
enter the ADJUST LIST.
Reduce photo to 13.5%
ADJUST LIST
MODEL SELECT
Main
Rotate the ROLLER to the right until MIX 1 is highlighted on screen.
Reduce photo to 13.5%
ADJUST LIST
9
SWASH MIX
MIX 1
MIX 2
Main
