123 SPEKTRUM DX6i • RADIO PROGRAMMING GUIDE
SwAShPlATE MIXING
The Swashplate Mix screen adjusts the amount and direction of travel for the aileron, elevator and pitch functions.
For example, if more aileron travel is desired, increasing the aileron swashplate mix value will increase the overall
travel of the servos necessary to achieve greater aileron throw. Defaults are set to +60%.
Note: Negative swashplate values are available which will reverse the direction of that function.
Use Servo Reversing (page 87) to change the direction of individual servos in conjunction with
positive or negative swashplate mix values to reverse the direction of all the servos associated with
that function to achieve the correct travel direction of the swashplate.
ACCESSING ThE SwAShPlATE MIX fUNCTION
With the transmitter already powered on and the main screen displayed, press and release the ROLLER to
enter the ADJUST LIST.
Reduce photo to 13.5%
ADJUST LIST
MODEL SELECT
Main
Rotate the ROLLER to the right until SWASH MIX is highlighted on screen.
Reduce photo to 13.5%
ADJUST LIST
8
PITC CUR
SWASH MIX
MIX 1
Main
