72 SPEKTRUM DX6i • RADIO PROGRAMMING GUIDE
Rotate the roller to select the desired master channel.
• THRO: Throttle
• AILE:
Aileron
• ELEV: Elevator
• RUDD: Rudder
• GEAR: Retractable Landing Gear
• FLAP:
Flap
Press the roller to deselect the master channel then rotate the roller to select the slave channel.
Press the roller to access the slave channel selection.
Rotate the roller to select the desired slave channel.
• THRO: Throttle
• AILE:
Aileron
• ELEV: Elevator
• RUDD: Rudder
• GEAR: Retractable Landing Gear
• FLAP:
Flap
SElECTING ThE MIXING vAlUES
Rotate the roller to highlight the desired rate and direction.
Reduce photo to 13.5%
MIX 1
THRO≥ THRO ACT
RATE D 0% U 0%
SW AIL D/R TRIM ACT
List
Press the roller to access the rate value.
Using the roller, rotate to adjust the desired mixing values. Note that positive (+) and negative (-) values are
available and affect the direction of the slave servo travel.
After the desired value is programmed press the roller to deselect the value.
