43 SPEKTRUM DX6i • RADIO PROGRAMMING GUIDE
wING TAIl MIX
The DX6i offers three different wing types to choose from: Normal, Dual aileron and Elevon (also called Delta
mixing). In addition, V-Tail mixing is available from this screen.
NORMAl
When the DUALAILE and ELEVON wing function are INH, Normal wing type is selected. Use this wing type with
common aircraft that utilize only one servo for both ailerons. Normal is the default setting.
When the V-tail function is INH, normal tail function (separate elevator and rudder) is selected.
DUAl AIlERON wING TyPE SElECTION
Dual Ailerons require the use of one servo for each aileron and allow the use of ailerons as flaps or spoilers. This
function also allows the precise independent adjustment of up and down travel, and independent sub-trim and
differential of each aileron.
v-TAIl SElECTION
V-tail combines the elevator and rudder channel to provide pitch and yaw control when using a V-tail equipped
airplane. This function also allows the precise independent adjustment of up and down travel, and independent
sub-trim and dual rate adjustments of the V-tail’s control surfaces.
ElEvON wING TyPE SElECTION
Elevon wing arrangements combine the function of ailerons with the function of the elevator to allow precise
control of both roll and pitch.
TO ENTER ThE wING TAIl MIX fUNCTION
Press the ROLLER and hold while turning on the transmitter. When SETUP LIST appears on screen
release the roller.
Alternatively the setup list can be accessed from the main screen by pressing the roller to access the ADJUST LIST,
then scrolling through the ADJUST LIST by rolling the roller to highlight SETUP LIST, then pressing the roller.
Reduce photo to 13.5%
SETUP LIST
MODEL TYPE
Main
