Allied Telesis AT-8326GB User Manual
Page 54
AT-8326GB Installation Guide
54
Figure 27 illustrates a stack of six switches.
Figure 27 A Stack of Six Switches
Note
Never add or remove an LDVS cable when the switches are
powered ON.
STACK IN
STACK OUT
STACK IN
STACK OUT
STACK IN
STACK OUT
STACK IN
STACK OUT
STACK IN
STACK OUT
STACK IN
STACK OUT
