AT-8326GB Installation Guide
39
Network Topologies
This section illustrates several of the network topologies you can create
with the AT-8326GB Fast Ethernet switches.
Power
Workgroup
Topology
The topology shown in Figure 20 is commonly referred to as a power
workgroup topology. Each workstation or node is connected directly to
a port on an AT-8326GB Fast Ethernet switch, giving each node a
dedicated data link to the switch for best performance and reliability.
The devices can operate at either 10 Mbps or 100 Mbps.
Figure 20 Power Workgroup Topology
FAULT PWR
AT-8326GB 24 + 2G Managed Switch LNK/ACT
FDX/COL
GIGA LNK/ACT
GIGA FDX/COL
STACK ID
RS-232
Legend
10 Mbps
100 Mbps
AT-8326GB Fast
Ethernet Switch
