Slave switch master switch – Allied Telesis AT-8326GB User Manual
Page 53
AT-8326GB Installation Guide
53
Figure 26 illustrates a stack of two switches connected with one LVDS
cable between the STACK OUT port on the master switch and the STACK
IN port on the slave switch.
Figure 26 Stack of Two Switches with LVDS Cable
STACK IN
STACK OUT
100-240 VAC
STACK IN
STACK OUT
100-240 VAC
Slave switch
Master switch
