Gigabit connector leds – Allied Telesis AT-8326GB User Manual
Page 23
AT-8326GB Installation Guide
23
Gigabit
Connector LEDs
Figure 11 Gigabit Connector LEDs
Ports 25 and 26 each have two connector LEDs on the front panel that
indicate which connector type is being used for each port: the RJ-45 or
the GBIC. The connector LEDs for each port are located to the left of the
RJ-45 connectors and to the right of the GBIC slots.
Connector LEDs
RS-232
