AT-8326GB Installation Guide
51
3. Slide the GBIC module into one of the GBIC slots in the front of the AT-
8326GB switch. The GBIC module is completely seated in the slot
when it clicks into place.
Figure 25 Installing a GBIC Module
4. If you purchased two GBIC modules for the switch, repeat this
procedure to install the second module.
Note
In order to use a GBIC module in Port 25 or 26, you must configure
the port in the management software to operate as a GBIC port and
not as a twisted pair port. For instructions, refer to the AT-S41
Management Software User’s Guide. When you change the port
setting in the management software to GBIC, the GBIC connector
LED to the right of the GBIC slot will turn green.
