Location of Components
Figure 1 illustrates the front panel of the AT-8326GB Fast Ethernet
Switch.
Figure 1 AT-8326GB Front Panel
Figure 2 illustrates the back panel.
Figure 2 Back Panel
FAULT
PWR
LNK/ACT
FDX/COL
GIGA
LNK/ACT
GIGA
FDX/COL
STACK ID
RS-232
GBIC
RS232
System and Port LEDs
10/100Base-TX Ports
Terminal Port
Slots
10/100/1000Base-T Ports
STACK IN
STACK OUT
100-240 VAC
AC Power Connector
Stacking Ports
