Stack id leds – Allied Telesis AT-8326GB User Manual
Page 20
AT-8326GB Installation Guide
20
Stack ID LEDs
Figure 9 Stack ID LEDs
The stack ID LEDs indicate the switch’s position in a switch stack. Since
you can stack up to six AT-8326GB switches, there are six stack ID LEDs.
For instructions on how to create a switch stack, refer to Creating a
Switch Stack on page 52.
FAULT
PWR
AT-8326GB
24 + 2G Managed Switch
LNK/ACT
FDX/COL
GIGA
LNK/ACT
GIGA
FDX/COL
STACK ID
Stack ID LEDs
