Chapter 21: Port-based and Tagged VLANs
350
Secton V: Virtual LANs
Modifying a VLAN
This procedure explains how to add or remove ports from a VLAN. When
modifying a VLAN, note the following:
You cannot change the VID of a VLAN.
You cannot change the name of a VLAN from a web browser
management session, but you can from a local or Telnet session.
You cannot modify VLANs when the switch is operating in one of the
multiple VLAN modes.
To modify a VLAN, perform the following procedure:
1. From the home page, select Configuration.
The System page is displayed with the General tab selected by
default, as shown in Figure 5 on page 38.
2. From the Configuration menu, select the Layer 2 option.
The Layer 2 page is displayed with the MAC Address tab selected by
default, as shown in Figure 25 on page 94.
3. Select the VLAN tab.
The VLAN tab is shown in Figure 143 on page 346.
4. Click the button next to the name of the VLAN you want to modify.
5. Click Modify.
The Modify VLAN page for the VLAN is displayed.
6. To add or remove ports from the VLAN, click on the appropriate ports
in the switch image.
Clicking repeatedly on a port toggles the port through the following
possible settings:
7. Click Apply.
Untagged port
Tagged port
Port is not a member of the VLAN
