AT-MFC2012LC and AT-MCF2012LC/1 Media Converter Modules Installation Guide
63
100Base-FX Fiber Optic Port Specifications
Table 11 lists the specifications for the 100Base-FX fiber
optic ports on the AT-MFC2012LC module.
Table 12 lists the specifications for the 100Base-FX fiber
optic ports on the AT-MFC2012LC/1 module.
Table 11. Fiber Optic Port Specifications for the
AT-MFC2012LC Module
General
Maximum Distance 2 km
Fiber Optic Cable 50/125 µm or 62.5/125
µm (core/cladding)
multimode fiber optic
cable
Transmitter
Wavelength 1310 nm
Output Optical Power -20 dBm min.
-14 dBm max.
Receiver
Wavelength 1310 nm
Sensitivity -31 dBm max.
Maximum Input Power -14 dBm min.
Table 12. Fiber Optic Port Specifications for the
AT-MFC2012LC/1 Module
General
Maximum Distance 20 km (12.4 mi.)
Fiber Optic Cable 9/125 µm single-mode
Transmitter
Wavelength 1310 nm
Output Optical Power -15 dBm min.
-8 dBm max.
