AT-MCF2012LC and AT-MCF2012LC/1 Media Converter Modules Installation Guide
27
Twisted Pair Port Flashing
Green or
Amber The twisted pair port of the channel
can establish a 100 Mbps (green) or
10 Mbps (amber) link with its
networking device, but the fiber optic
port is unable to establish a link with
its remote device. For troubleshooting
suggestions, refer to Problem 4 in
Chapter 3, “Troubleshooting” on page
55.
Fiber Optic Port Off
Twisted Pair Port Off The fiber optic port of a channel can
establish a 100 Mbps link with its
networking device, but the twisted pair
port is unable to establish a link with
its local device. For troubleshooting
suggestions, refer to Problem 3 in
Chapter 3, “Troubleshooting” on page
55.
Fiber Optic Port Flashing
Green
Twisted Pair Port Flashing
Green or
Amber Both ports in the channel can
establish a link to a networking device,
but one of the ports is connected to
another media converter that also
supports the Smart MissingLink
feature, forming a chain of converters.
A link has been lost on one of the
ports in the chain, causing a ripple
affect through the chain of converters.
Alternatively, one of the ports is only
able to form an intermittent link with its
networking device.
For troubleshooting suggestions, refer
to Problem 8 in Chapter 3,
“Troubleshooting” on page 55.
Fiber Optic Port Flashing
Green
Table 5. “L” Link LEDs in the Smart MissingLink Mode (Continued)
Channel Port
Link LED
State
Description
