Chapter 1: Overview

26

Link LEDs and the Smart MissingLink Mode

The Smart MissingLink mode pulses the transmitter on a
port when its companion port in a channel loses or has not
established a link to its networking device. The blinking Link
LED can make it easier for you to identify and troubleshoot
a link problem on the two ports of a channel. For more
information on this operating mode, refer to “Smart
MissingLink Mode” on page 33
.

Table 5 lists the combinations and definitions of the Link
LEDs for the twisted pair port and fiber optic port of a
channel operating in this mode.

Table 4. “L” Link LEDs in the MissingLink Mode

Channel Port

Link LED

State

Description

Twisted Pair Port

Off

One or both ports in the channel can
not establish a link with a networking
device.

Fiber Optic Port

Off

Twisted Pair Port

Steady
Green or
Amber

Both ports in the channel have
established a link with a networking
device. The twisted pair port is
operating at 100 Mbps (green) or 10
Mbps (amber) link and the fiber optic
port at 100 Mbps.

Fiber Optic Port

Steady
Green

Table 5. “L” Link LEDs in the Smart MissingLink Mode

Channel Port

Link LED

State

Description

Twisted Pair Port

Off

Neither port in the channel has
established a link with a networking
device.

Fiber Optic Port

Off

Twisted Pair Port

Steady
Green or
Amber

Both ports in the channel have
established a link with a networking
device. The twisted pair port is
operating at 100 Mbps (green) or 10
Mbps (amber) link and the fiber optic
port at 100 Mbps.

Fiber Optic Port

Steady
Green
