background image

Chapter 2: Installation

44

Planning the Installation

10/100Base-

TX Twisted

Pair Cabling

Table 7 lists the cable requirements for the 10/100Base-TX
twisted pair ports. For port pinouts, refer to “10/100Base-TX
Port Pinouts” on page 62.

Note

The default setting for a twisted pair port is Auto-
Negotiation and auto-MDI/MDI-X. In the default
setting, a port’s speed, duplex mode, and MDI/MDI-X
setting are set automatically. Disabling Auto-
Negotiation and manually configuring a port requires
the optional management module for the chassis.

Table 7. Twisted Pair Cable and Distances

Speed

Cable Type

Maximum

Operating

Distance

10 Mbps

Standard TIA/EIA 568-B-
compliant Category 3 or
better shielded or
unshielded cabling with
100 ohm impedance and
a frequency of 16 MHz.

100 m (328 ft)

100 Mbps

Standard TIA/EIA 568-A-
compliant Category 5 or
TIA/EIA 568-B-compliant
Enhanced Category 5
(Cat 5e) shielded or
unshielded cabling with
100 ohm impedance and
a frequency of 100 MHz.

100 m (328 ft)
