AT-9400 Stack Installation Guide

69

Verifying a Stack

with Dynamic

Module ID

Numbers

To verify the installation of a stack with dynamic module ID numbers on
the switches, perform the following procedure:

1. After powering on the stack, wait a least two minutes. This is to give

the switches sufficient time to initialize their management software and
complete the discovery process.

2. Identify the master switch of the stack by examining the Stack MSTR

LED on the front panel of the switches. This LED will be green on the
master switch. (Do not confuse the Stack MSTR LED with the Status
MASTER LED. The latter is used with enhanced stacking, a feature
not supported on a stack.)

Note

If all the Stack MSTR LEDs are off, the discovery process may have
encountered a problem. For suggestions on how to resolve it, refer
to “Troubleshooting the Discovery Process” on page 71.

3. Place a label on the master switch’s front panel to make it easier to

identify.

4. Establish a local management session on the master switch. For

instructions, refer to “Starting a Local Management Session” on
page 53.

5. Enter the following command:

show stack

The command lists the switches of a stack. An example is show in
Figure 30 on page 68.

6. Match the units in the table from the command with the physical

devices by comparing the MAC addresses of the units, found on a
label on the back panels.

7. Attach labels to the front of the switches with their module ID numbers

(e.g., 1, 2, etc.) from the command. You must use these numbers
when you configure the devices with the management software.

Note

If you add or remove a switch from the stack that has dynamic stack
ID numbers, the stack ID number assignments may change. That
could have a significant impact on the configuration of the devices.
For further information, refer to Chapter 1, “Overview” in the AT-S63
Stack Command Line Interface User’s Guide
.
