17
Chapter 1
Overview
This chapter contains the following sections:
ˆ “Introduction” on page 18
ˆ “Switch Descriptions” on page 19
ˆ “10/100/1000Base-T Twisted Pair Ports” on page 22
ˆ “SFP Transceiver Slots” on page 24
ˆ “XFP Transceiver Slots” on page 25
ˆ “Redundant Twisted Pair Ports” on page 26
ˆ “Compact Flash Card Slot” on page 27
ˆ “Port LEDs” on page 28
ˆ “System LEDs” on page 30
ˆ “Stack LEDs” on page 31
ˆ “AT-StackXG Stacking Module” on page 32
ˆ “Terminal Port” on page 33
ˆ “AT-RPS3204 Redundant Power Supply” on page 34
ˆ “AC Power Connector” on page 35
Note
Do not begin the installation procedures in this guide until you have
read the Software Release Notes that are included with the latest
release of the AT-S63 Management Software or reviewed the latest
version of the AT-S63 Stack Command Line Interface User’s Guide.
A stack may not be suitable for all network environments because of
the limited number of supported features. If your network
requirements include features that are not supported in a stack,
install the switches as stand-alone devices.
Allied Telesis also recommends that you read Chapter 1, “Overview”
in the AT-S63 Management Software Features Guide and Chapter
1, “Overview” in the AT-S63 Stack Command Line Interface User’s
Guide before you begin the installation. An understanding of the
background information in the chapters will make the installation
easier.
