AT-MCF2000 Multi-channel Media Converter Chassis Installation Guide
27
4. Attach a rack-mount bracket to one side of the chassis
using four of the screws included with the unit, as
shown in Figure 7.
Figure 7. Attaching the Rack-Mount Brackets
5. Install the second rack-mount bracket on the other side
of the chassis using the four remaining screws.
6. Mount the switch in the 19-inch rack using standard
screws (not provided).
Caution
The chassis may be heavy. You may need assistance
to safely install the chassis in the rack.
1109-a
AT-M
CF2 00 0
1
2
AT-MCF2KPNL1
AT-MCF2KPNL1
A T -MCF2000
