AT-MCF2000 Multi-channel Media Converter Chassis Installation Guide

15

Hardware Features

Figure 2 shows the front panel of the AT-MCF2000 chassis.

Figure 2. Front Panel

Figure 3 illustrates the back panel of the AT-MCF2000
chassis.

Figure 3. Back Panel

Media Converter

Module Slots

1107-a

AT-MCF2KPNL1

AT-MCF2KPNL1

1

2

A

T

-MCF2000

Management Module

Slot

or Fan Module Slot

Power Supply Module

1108-a

AT-MCF2KPNL2

AT-MCF2KPNL2

AT-MCF2KPNL3

MANAGEMENT

A

B

or Fan Module Slot

Power Supply Module
