Chapter 2: Installation
26
Installing the Chassis in a Rack
This procedure explains how to install the chassis in a 19-
inch rack. Depending on its placement in the rack, it may be
easier for you to install all of the modules in the chassis
before you mount it in the rack. If so, you can perform steps
1 through 3 in this procedure and then go to the next
procedure to begin to install the modules. After the modules
are installed, return to this section and complete the
procedure starting with step 4.
Installing the chassis in a rack is optional. The unit can be
installed on a desktop.
To install the chassis in a standard 19-inch rack, perform
the following procedure:
Note
Steps 1 to 3 are optional. They instruct you to remove
the plastic feet from the bottom panel of the chassis.
The plastic feet are unnecessary when the chassis is
installed in a rack.
1. Place the unit upside down on a level, secure surface.
2. Using a flat-head screwdriver, remove the snap-on
plastic feet from the bottom of the chassis, as shown in
Figure 6.
Figure 6. Removing the Chassis Feet
3. Turn the chassis over.
