AT-WNU300N IEEE802.11b/g/n 2T2R Wireless Fast USB Adapter User Manual 29
Figure 44: PIN Code
3. Select the wireless AP from WPS AP List, and the click on “PIN” to connect to the wireless AP.
As the connection successes, the network will be shown in the WPS Profile list.
Figure 45: WPS Successfully
Note: After running WPS on wireless AP, you need to push “PIN” button on wireless adapter
in 120 seconds. Otherwise you need to perform the procedure from step 1.
Enter Wireless Adapter PIN code
1. In AT-WNU300N Wireless Utility, go to “WPS”. Switch the Config Mode to “Enrollee”. Then record
the 8-character PIN code. You can press “Renew” to get a new PIN code.
Figure 46: Enrolee Mode
2. In wireless AP utility, input the PIN code and then run WPS.
3. Go back to AT-WNU300N Wireless Utility. In WPS tab, click on “Rescan” to get the WPS signal
from wireless AP.
