AT-WNU300N IEEE802.11b/g/n 2T2R Wireless Fast USB Adapter User Manual 19
Chapter 4: Configure Wireless Network
You can configure your wireless network by AT-WNU300N Wireless Utility in Windows XP, Vista, and
2000. Before the configuration, please confirm that the wireless adapter is within the range of wireless AP.
Weak signal might result in connection failure.
Run AT-WNU300N Wireless Utility
After installing AT-WNU300N Wireless Utility on your computer, AT-WNU300N IEEE802.11b/g/n 2T2R
Wireless Fast USB Adapter will automatically search and connect to an open wireless network nearby.
Please double click on icon at the tray to open AT-WNU300N Wireless Utility.
Note: If you do not see the icon at the tray, go to “Start” “All Programs”
“AT-WNU300N” and click on “AT-WNU300N Wireless Utility” to open it.
The First View of AT-WNU300N Wireless Utility
Figure 18: The First View of AT-WNU300N Wireless Utility
Main Menu To configure the wireless adapter. Please refer to Chapter 5: Utility
Introduction for the details
Configuration It shows main part of configuration
See more/less Switch to see more or less information
Connection Status It shows current connection status
Start Wireless Network Connection
This session describes the procedure of connecting to a wireless AP. You need to configure AT-WNU300N
IEEE802.11b/g/n 2T2R Wireless Fast USB Adapter in accordance with the wireless AP’s encryption setting.
