Allied Telesis AT-WNU300N - Manual (Page 24)

24 AT-WNU300N - IEEE802.11b/g/n 2T2R Wireless Fast USB Adapter - User Manual
Note: All settings must be exactly the same with the wireless AP, otherwise it will result in a
failure.
Connect to a Non-broadcasting Network
For security reasons, wireless AP might hide its SSID. To connect to a non-broadcasting network, you are
prompted for a SSID and a key. You can start either with “Profile” or “Network”. Please perform the
following procedure.
1. In Profile tab, click on “Add”.
Figure 31: Config Utility
2. Give the profile a name to identify, and then input SSID. The SSID must be exactly the same with the
wireless AP.
Figure 32: Configure Profile Name
3. In “Auth.\Encry.” tab, configure corresponding setting, including authentication, encryption and the
Key. Click on “OK” to apply the settings.
