x510DP-52GTX Installation Guide
59
Installing Power Supply Modules
Overview
The AT-x510DP-52GTX switch has two rear slots for hot-swappable
power supplies.
The switch is supplied with a factory installed blank panel that covers both
power supply slots, and with a separate blank panel to use if you only
install one power supply.
Power supply options are:
ˆ For AC power with back-to-front air flow, one or two AT-PWR100R
power supply modules - see Figure 9 on page 33
ˆ For AC power with front-to-back air flow, one or two AT-PWR250
power supply modules - see Figure 10 on page 33
ˆ For DC power with back-to-front air flow, one or two
AT-PWR250R-80 power supply modules - see Figure 11 on page
33
The installation procedure is identical for each power supply.
Installing a
Power Supply
To install a power supply, perform the following procedure:
1. Remove the module from the shipping package.
Note
Store the packaging material in a safe location. You must use the
original shipping material if you need to return the unit to Allied
Telesis.
