Page 19
x510DP-52GTX Installation Guide
19
Management Panel
Figure 3 identifies the components in the management panel on the AT-
x510DP-52GTX switch.
Figure 3. AT-x510DP-52GTX Management Panel
Console
eco-friendly
Button
Switch
Port
ID LED
Management
USB Port
