BTS Aisle Containment Manual, Rev. 1.0 ___ December 2013
Chatsworth Products 31
AISLE CONTAINMENT DOOR SYSTEM
INTRODUCTION
The Aisle Containment Door Systems from Chatsworth Products, Inc. (CPI) have been
developed to meet a wide range of application needs. The door systems can be
installed in aisle widths that are between two and three tiles wide. The door systems
are designed to be compatible with F-Series TeraFrame
® and GF-Series GlobalFrame®
cabinets that are between 42U minimum and 52U maximum height (77.8” – 98.9”). Door
systems are available in three sliding options including: double-door, single-door left-
hand sliding and single-door right-hand sliding. Four finish options are available
including black and glacier white colors with either anodized aluminum door frames or
color-matched door frames. The system can be installed onto slab floors or raised
access floors. All systems include a stylish anodized aluminum door frame with full-
height, clear polycarbonate inserts, an automatic close system with speed control
damper, and a detent-open catch.
COMPONENTS
The doors ship unassembled in a single crate with assembly and installation hardware:
Door(s) - 1 or 2 pieces Sides - 2 pieces
Rail Assembly - 1 piece Assembled Double Door
