15 Appendix
15.1 Optical Characteristics
Table 76: Optical Characteristics
Pixel Layout (WxH) 240 x 128 pixels
Display Area 107.95 x 57.55mm
Dot Size 0.40 x 0.40mm
Dot Pitch 0.45 x 0.45mm
Viewing Angle (Vertical) +35 o /- 20 o from Normal
Viewing Angle (Horizontal) +30 o /- 30 o from Normal
LED Backlight Life(GW&WB) 10,000 hours typical
LED Backlight Life(YG) 50,000 hours typical
Backlight white or yellow-green STN LED
NOTE To prolong life, it is recommended that the backlight be turned off when the
display is not in use.
15.2 Specifications
15.2.1 Environmental
Table 77: Environmental Specifications
Operating Temperature 0 ◦ C to +50 ◦ C
Storage Temperature -20 ◦ C to +70 ◦ C
Operating Relative Humidity 60% max non-condensing
Vibration (Operating) 4.9 m/s 2 XYZ directions
Vibration (Non-Operating) 19.6 m/s 2 XYZ directions
Shock (Operating) 29.4 m/s 2 XYZ directions
Shock (Non-Operating) 490 m/s 2 XYZ directions
Matrix Orbital GLT240128 61
