9.2 Set Touch Region
Syntax Hexadecimal 0xFE 0x84 [num] [x] [y] [w] [h] [keyDown] [keyUp]
Decimal 254 132 [num] [x] [y] [w] [h] [keyDown] [keyUp]
Parameters Parameter Length Description
num 1 Region number, each region must
be identified by a unique number,
single byte (32 region max).
x 1 X co-ordinate of the top left corner
of the region, single byte (0-Xmax).
y 1 Y co-ordinate of the top left corner
of the region, single byte (0-Ymax).
w 1 Width of the region, single byte
(0-Xmax).
h 1 Height of the region, single byte
(0-Ymax).
keyDown 1 Value returned when region is
pressed, single byte (0-255).
keyUp 1 Value returned when region is
released, single byte (0-255).
Description This command creates a touchpad region that reports the key down or
key up values saved to it when a press or release respectively is detected
within the region defined.
Remembered Yes
9.3 Delete Touch Region
Syntax Hexadecimal 0xFE 0x85 [num]
Decimal 254 133 [num]
Parameters Parameter Length Description
num 1 Region number to be deleted, single
byte.
Description This command deletes a previously created touchpad region, unique key
preses will no longer be received from events in the area defined by the
deleted region. All events in undefined regions will return 255.
Remembered Yes
9.4 Delete All Touch Regions
