Parameters Parameter Length Description
color 1 Drawing color (0: White, 1-255:
Black).
x1 1 Left bounds.
y1 1 Top Bounds.
x2 1 Right Bounds.
y2 1 Bottom Bounds.
Description This command draws a solid rectangle in the specified color (0: White,
1: Black). The top left corner is specified by (x1,y1) and the bottom
right corner by (x2,y2). Since this command involves considerable
processing overhead, we strongly recommend the use of flow control,
particularly if the command is to be repeated frequently.
Remembered No
8.8 Initializing a Bar Graph
Syntax Hexadecimal 0xFE 0x67 [refID] [type] [x1] [y1] [x2] [y2]
Decimal 254 103 [refID] [type] [x1] [y1] [x2] [y2]
ASCII 254 “g” [refID] [type] [x1] [y1] [x2] [y2]
Parameters Parameter Length Description
refID 1 Reference number
type 1 Type of bar graph.
x1 1 Left bounds.
y1 1 Top Bounds.
x2 1 Right Bounds.
y2 1 Bottom Bounds.
