Description Syntax Page
Draw a Rectangle Hexadecimal 0xFE 0x72 [color] [x1] [y1] [x2] [y2]
Decimal 254 114 [color] [x1] [y1] [x2] [y2]
ASCII 254 “r” [color] [x1] [y1] [x2] [y2]
32
Drawing a Solid
Rectangle Hexadecimal 0xFE 0x78 [color] [x1] [y1] [x2] [y2]
Decimal 254 120 [color] [x1] [y1] [x2] [y2]
ASCII 254 “x” [color] [x1] [y1] [x2] [y2]
32
Initializing a Bar Graph Hexadecimal 0xFE 0x67 [refID] [type] [x1] [y1] [x2] [y2]
Decimal 254 103 [refID] [type] [x1] [y1] [x2] [y2]
ASCII 254 “g” [refID] [type] [x1] [y1] [x2] [y2]
33
Drawing a Bar Graph Hexadecimal 0xFE 0x69 [ref] [value]
Decimal 254 105 [ref] [value]
ASCII 254 “i” [ref] [value]
34
Initializing a Strip Chart Hexadecimal 0xFE 0x6A [refID] [x1] [y1] [x2] [y2]
Decimal 254 106 [refID] [x1] [y1] [x2] [y2]
ASCII 254 “j” [refID] [x1] [y1] [x2] [y2]
34
Shifting a Strip Chart Hexadecimal 0xFE 0x6B [ref]
Decimal 254 107 [ref]
ASCII 254 “k” [ref]
35
14.6 Touchpad
Description Syntax Page
Set Touch Region Hexadecimal 0xFE 0x84 [num] [x] [y] [w] [h] [keyDown] [keyUp]
Decimal 254 132 [num] [x] [y] [w] [h] [keyDown] [keyUp]
37
Delete Touch Region Hexadecimal 0xFE 0x85 [num]
Decimal 254 133 [num]
37
Delete All Touch Regions Hexadecimal 0xFE 0x86
Decimal 254 134
37
Set Touch Mode Hexadecimal 0xFE 0x87 [mode]
Decimal 254 135 [mode]
38
Set Region Reporting
Mode Hexadecimal 0xFE 0x88 [mode]
Decimal 254 136 [mode]
38
Set Dragging Threshold Hexadecimal 0xFE 0x89 [threshold]
Decimal 254 137 [threshold]
39
Set Pressure Threshold Hexadecimal 0xFE 0x8A [threshold]
Decimal 254 138 [threshold]
39
Run Touchpad
Calibration Hexadecimal 0xFE 0x8B
Decimal 254 139
39
14.7 Display Functions
